H-TV-200 Series

　　HEAVY DUTY 2” CRASHWORTHY INTERNAL SOLENOID TANK VALVE

　　大流量2”內置式防碰撞電磁瓶口閥

　　Key Features

　　Patented solenoid tank valve that mounts the coil and plunger inside the tank protecting it from any external impact and environmental exposure. Temperature sensor mounted inside the tank allows for fuel gauge correction or fuel dispenser feedback system. Tank valve also includes an integrated PRD along with manual shut off.

　　? Almost 20 years in service in OEM applications

　　? The solenoid lock off is located inside the cylinder, providing real crash and environmental protection

　　? Pipe away T-PRD

　　? Internal temperature sensor

　　? Light weight aluminium design

　　? 12 V and 24 V solenoid coils available

　　? 350 Bar service pressure

　　主要特性

　　具有專利技術的電磁瓶口閥把線圈和閥芯設計在氣瓶內部，這樣可以保護它們不受碰撞和外界環境的影響。溫度傳感器裝在氣瓶里面，可以用于氣量表數值的修正或者燃?xì)饧託鈾C(jī)反饋系統。同時該瓶口閥也集成了手動切斷閥和壓力釋放閥。

　　? 超過20年的OEM應用經驗;

　　? 電磁切斷閥位于氣瓶內部，保護其不受碰撞和外界環境的影響;

　　? 集成溫度型壓力釋放閥;

　　? 集成溫度傳感器;

　　? 輕量化鋁制機體;

　　? 兼容12V或者24V系統;

　　? 最大支持350bar系統壓力。
